Intermatic FD15MWC Spring Wound Countdown Timer – Decorator Style 125-277 VAC One Day Deal

The Intermatic FD15MWC spring wound countdown timer operates on a voltage range of one hundred twenty-five to two hundred seventy-seven volts alternating current. This mechanical timer replaces standard wall switches and is suitable for both single and multi-gang installations. The timer does not require electricity to function, making it a reliable solution for managing on-times for fans, lighting, motors, heaters, and other high-energy devices.

• 15-minute timer with spring wound design
• SPST contact configuration
• Easy installation and replacements for existing wall switches

Product Highlights

Energy-efficient design requires no electricity and automatically limits on times for various applications in residential or commercial settings.

Product Information

Standard Information

• Brand: Intermatic
• MPN: FD15MWC

Technical Specifications

• Voltage: 125-277 VAC
• Amperage Rating: 15 Amp
• Contact Configuration: SPST – 1 NO
• Temperature Rating: -40 to 104 degrees F
• Dimensions: 2.79 inches height x 1.6 inches width x 1.19 inches depth
• Frequency: 50/60 Hz
• Mounting Type: Wall
• Applications: Indoor use for lighting, fans, electric motors, and HVACR
